Description
- Lowers Front 18mm, Rear 33mm
- High Performance Handling and Aggressive Good Looks.
- Lower Center of Gravity.
- Stop Quicker Corner Faster and get Better MPG!
- Progressive Spring Design for Excellent Ride Quality.
- Million-Mile Warranty
Note; Will not fit non SRT vehicle’s
Front
OE rate: 94 N/mm (537 lbs/in)
PRO-KIT progressive rate: 103 – 153 N/mm (588 – 874 lbs/in)
Bump-stop: New Eibach Bump Stop
Damper: OE
Tubing: n/a
OE wheel center to fender: 504 mm (19.8 in)
PRO-KIT wheel center to fender: 486 mm (19.1 in)
PRO-KIT can be aligned to OE Specs: Yes
Front Alignment
OE Camber = -1.6 deg (+/-0.5 deg)
OE Caster = 5.2 deg (+/-0.6 deg)
OE Toe = 0.10 deg (+/-0.6 deg)
PRO-KIT Camber = -1.7 deg
PRO-KIT Caster = 5.4 deg
PRO-KIT Toe = -0.05 deg
Approximate installation time: 1.5 hrs
Rear
OE rate: 157 N/mm (897 lbs/in)
PRO-KIT progressive rate: 70 – 172 N/mm (400 – 982 lbs/in)
Damper: OE
Bump-stop: OE
Tubing: n/a
OE wheel center to fender: 534 mm (21.0 in)
PRO-KIT wheel center to fender: 501 mm (19.7 in)
PRO-KIT can be aligned to OE specs: Yes
Rear Alignment:
OE Camber = -1.3 (+/-0.5 deg)
OE Toe = 0.25 deg. (+/-0.20 deg)
PRO-KIT Camber = -1.8 deg
PRO-KIT Toe = 0.05 deg
Approximate installation time: 1.5 hrs
